All the loving care of the best stockmaker and the meticulous attention to detail of the master machinist will not make a gun shoot any straighter than the accuracy capability of the barrel used. And, it is the insides of a barrel, that very small and vital area of lands and grooves over which the gunsmith has no control, that can determine whether the finished work of art is for shooting - or “just for looks”. Craftsmanship . . . not price . . . determines the quality of a barrel. But, by the same token, the customer willing to spend the money for a custom gun is shortsighted indeed, if he starts economizing and orders “just any old barrel so long as it’s cheap”. Furthermore, he is jeopardizing your reputation as a gun builder by making such a request. We, as your supplier, are laying our reputation (and yours, too!) on the line by offering you barrel blanks. They have got to be good or we are in trouble! Big trouble!! We must never sell you anything but that which will enlarge your stature with your trade. And, we feel that the Brownell Barrel, made for us by Ed Shilen, will do just that! Shilen barrels, either chrome moly or Stainless, are rifled with six lands and grooves by the “Cold Forming” process using carbide dies made in Shilen’s own plant under the most rigid controls. This rifling method achieves extremely close inside uniformity from breech to muzzle. Finished barrels are air-gauge inspected (air-gauged sensitivity is .00005" - five-one-hundred-thousandths!) and 6X borescope in- spected. All barrels, .22 through .30 caliber have groove tolerances within .0005" and uniformity within .0003" No straightening is done, and all barrels are completely stress-relieved. All stainless steel barrels are hand lapped at the factory. Only those barrels passing all spec tests are offered to the trade. Any barrel even slightly “suspect” is started through the production process again and bored to a large caliber. In no other way can quality and reputation be maintained. Slightly more expensive to produce - but vastly greater in quality and ultimate performance.
SPECS: 4140 chrome-moly or 416 Stainless Steel. METRIC: 1 " (2.5cm), 1 lb. (.45kg).
Special Orders: If no Stock # is shown in the chart, that barrel must be ordered on a Special Order basis. Special Orders require Full Payment in Advance and are non-cancelable and non-refundable. Allow 8-10 weeks for delivery. Not shipped prepaid.
Oppdag presisjon og kvalitet med CONTOUR #3 BARREL
CONTOUR #3 BARREL fra SHILEN er tilgjengelig i både krom-moly og rustfritt stål, og er designet for å gi deg den beste presisjonen i skyting. Med en 22 kaliber og 1-14 twist, er dette løpet laget for å tilfredsstille selv de mest kresne skyttere.
Produktegenskaper:
- Materiale: 4140 krom-moly eller 416 rustfritt stål
- Rifling: Seks lands og groper, produsert med "Cold Forming" prosessen
- Inspeksjon: Luft-gauge inspisert med en følsomhet på .00005" og 6X borescope inspeksjon
- Toleranser: Grooves innen .0005" og uniformitet innen .0003"
- Stressavlastning: Alle løp er helt stressavlastet
- Håndlapning: Alle rustfrie stål-løp er håndlapet på fabrikken
Det er viktig å merke seg at kvaliteten på løpet er avgjørende for nøyaktigheten til våpenet. En kunde som velger å spare penger ved å bestille et billig løp, setter både sin egen og vår reputasjon som våpenbygger i fare. Vi tilbyr kun løpet som vi vet vil heve din status i bransjen.
Spesialbestillinger: Hvis det ikke er oppgitt et lager # i tabellen, må løpet bestilles på spesialbestilling. Spesialbestillinger krever full betaling på forhånd og kan ikke kanselleres eller refunderes. Vennligst tillat 8-10 uker for levering. Ikke sendt fraktfritt.
